* * N E W F O R 2 0 1 8 * *

E-Track System & Accessories

ETLSB

ETHSB

ETBHB

ETTH

E-Track Accessories

	Designed to fit standard horizontal E-track
	Easy to use
	Powder coated black finish
	Made in the USA

ETSSB
ETLSB
ETBHB
ETHSB
ETTH

12" wide x 6 1/4" deep shelf for E-track, black
18" wide x 10" deep shelf for E-track, black
5 gallon bucket holder for E-track, black
8" x 8" stop plate for E-track, black
5 slot tool holder for E-track, black

Weight
3.9 lb
6.4 lb
3.5 lb
2.9 lb
5.8 lb

Std. Pack
1/bulk
1/bulk
1/bulk
1/bulk
1/bulk

* * N E W F O R 2 0 1 8 * *

Receiver Hitch Stair

Receiver Hitch Stair Extender Kit

	Extends #RHS2 beyond your tailgate in the down position
	Three adjustable lengths when used with #RHS2 stair: 19 1/2", 22 1/2" and 25 1/2" (back of top step to hitch pin hole)
	Weight capacity 250 lb

RHSE

receiver hitch stair extender kit for #RHS2

Weight
14.4 lb

Std. Pack
1/box

* * N E W F O R 2 0 1 8 * *

Ratchet Straps & Car Tie Downs

T510

1 1/2” Wide Ratchet Strap

	5,000 lb load rating
	Comes with double J-hooks

T510

1 1/2" x 10' tie down ratchet strap w/double J-hooks - 5,000 lb

Weight
3.6 lb

Std. Pack
10/bulk

* * N E W F O R 2 0 1 8 * *

Electrical Connectors

F724

Electrical Connector

F724

7 way blade (trailer) to 7 way blade (trailer) 24" lg with UL cable

Weight
6.85 lb

Std. Pack
20/bulk

* * N E W F O R 2 0 1 8 * *

Hitch Pins

HLWH

HPD3

HPSM

5/8” Hitch Pins

	HPSM designed for limited access receiver areas
	HPD3 and HLWH fit 3" receiver hitches

HPSM HPD3 HLWH	5/8" dead bolt lock hitch pin for 2" receivers 5/8" dead bolt lock hitch pin for 3" receivers 5/8" hitch pin with hole and retainer clip for 3" receivers	Weight 0.89 lb 0.93 lb 0.60 lb	Std. Pack 1/clam shell 1/clam shell 50/bulk*

*Available carded

* * N E W F O R 2 0 1 8 * *

Trailer Stake Pocket Tie Downs

TRWB

Rotating Trailer Stake Pocket Winch

	Fit 3 1/2" stake pockets
	Accommodates 2" straps
	Winch rotates for a better tie down point

TRWB		rotating 2" trailer stake pocket winch - 10,000 lb, black		Weight 7.4 lb		Std. Pack 6/bulk

* * N E W F O R 2 0 1 8 * *

Ball Mount Sets

EX26SI

7,500 Lb Capacity Economy Ball Mount Sets

These heavy-duty ball mount sets fit 2" receivers and include black ball mount, chrome hitch ball and 5/8" standard hitch pin. Fully assembled and ready to use. Packaged 3 in a tri-color box.

				Weight		Std. Pack
EX26SI EX32SI EX48SI EX34SI		2 1/2" drop ball mt., 8 3/4" long, 2" hitch ball set in color display box 2 1/2" drop ball mt., 8 3/4" long, 2 5/16" hitch ball set in color display box 4 3/4" drop ball mt., 9 " long, 2" hitch ball set in color display box 4 3/4" drop ball mt., 9 " long, 2 5/16" hitch ball set in color display box		10.0 lb 11.0 lb 10.7 lb 11.7 lb		3/box 3/box 3/box 3/box

* * N E W F O R 2 0 1 8 * *

Ball Mounts

XB26

7,500 Lb Economy Ball Mounts

These heavy-duty ball mounts fit into 2" receivers and have a load rating of 7,500 lb. Accommodate 1" shank hitch balls. Powder coated black finish.

				Weight		Std. Pack
XB26 XB48		2 1/2" drop ball mt., 8 3/4" long ball mount, black 4 3/4" drop ball mt., 9" long, long ball mount, black		7.7 lb 8.3 lb		1/box 1/box

* * N E W F O R 2 0 1 8 * *

Aluminum Ball Mount Combos

SZ10

20,000 Lb Capacity Steel Adjustable Ball Combos

These heavy-duty ball combos are made from solid steel and have a load rating of 20,000 lb. For use with any 2 1/2" receiver. Come with an easy-change reversible 2" and 2 5/16" ball.

				Weight		Std. Pack
SZ06 SZ10 SCLS		6" drop ball mount w/2" & 2 5/16" ball-20,000 lb, black 10" drop ball mount w/2" & 2 5/16" ball-20,000 lb, black dual lock set for #SZ06 and #SZ10, zinc		37.5 lb 42.0 lb 1.75 lb		1/box 1/box 1/box

* * N E W F O R 2 0 1 8 * *

Receiver Hitch Stabilizer Bracket and Clamp Plate

RS20

Receiver Stabilizer Bracket

	Stabilizes hitch accessories such as bike carriers, cargo carriers, etc. to prevent damage
	Clamps receiver bar tight for quiet, no wobble operation

RS20 RS25		2" receiver hitch stabilizer clamp 2 1/2" receiver hitch stabilizer clamp				Weight 2.42 lb 2.84 lb		Std. Pack 1/clam shell 1/clam shell

* * N E W F O R 2 0 1 7 - 18 * *

More Trailer Stake Pocket Tie Downs

T11B

T2WB

Trailer Stake Pocket Tie Downs

Fit 3 1/2" stake pockets

T55B T55Z T11B T11Z T12B T12Z T2WB T2WZ W2CZ WSJH W2ZS W2BZ		trailer stake pocket tie down with 1/2" ring - 5,000 MBS/1,600 WLL, black trailer stake pocket tie down with 1/2" ring - 5,000 MBS/1,600 WLL, zinc trailer stake pocket tie down with 1/2" ring - 12,000 lb, black trailer stake pocket tie down with 1/2" ring - 12,000 lb, zinc trailer stake pocket tie down with 5/8" ring - 12,000 lb, black trailer stake pocket tie down with 5/8" ring - 12,000 lb, zinc 2" trailer stake pocket winch - 10,000 MBS/3,333 WLL, black 2" trailer stake pocket winch - 10,000 MBS/3,333 WLL, zinc 2" lashing winch only - 10,000 MBS/3,333 WLL, black 2" x 27' tie down strap with J-hook - 10,000 MBS/3,333 WLL 20" winch bar for 2" lashing winch, zinc 35" winch bar for 2" lashing winch, zinc		Weight 2.3 lb 2.3 lb 3.8 lb 3.8 lb 4.7 lb 4.7 lb 6.9 lb 6.9 lb 3.2 lb 2.3 lb 1.7 lb 3.1 lb		Std. Pack 18/bulk 18/bulk 12/bulk 12/bulk 6/bulk 6/bulk 6/bulk 6/bulk 10/bulk 20/bulk 10/bulk 10/bulk

* * N E W F O R 2 0 1 7 - 18 * *

Receiver Tubes

RL08

2 1/2” Receiver Tubes

Manufactured from square steel tubing with reinforcement collar for added strength. Designed to fit all 2 1/2" ball mounts. Hitch pin hole included. Available unpainted. Custom sizes available.

RL08
RL12
RL18
RL24
RL36
RL48

8" receiver tube, black
12" receiver tube, black
18" receiver tube, black
24" receiver tube, black
36" receiver tube, black
48" receiver tube, black

Weight
6.0 lb
8.7 lb
12.7 lb
17.0 lb
25.0 lb
35.0 lb

Std. Pack
4/bulk
4/bulk
1/bulk
1/bulk
1/bulk
1/bulk

* * N E W F O R 2 0 1 7 - 18 * *

Receiver Tubes

AZF8

2 1/2” Aluminum Adjustable Ball Combos

These smooth face heavy-duty combos are made from aluminum and have a load rating of 18,000 lb. For use with any 2 1/2" receivers. Come with easy-change reversible 2" and 2 5/16" ball.

Part # AZF6 AZF8 AZF1		Length 8 1/2" 9" 9"		Drop 6" 8 1/4" 10"		Lift 7" 8 3/4" 11"		MGTWR/MTW 12,000-18,000/1800 12,000-18,000/1800 12,000-18,000/1800	Weight 23 lb 24 lb 25 lb	Std. Pack 1/box 1/box 1/box
RPL2	locking pins for 2 1/2" receiver aluminum combos, set of 2								1.7 lb	1/clam

* * N E W F O R 2 0 1 7 - 18 * *

Hitch Adapters

3” Receiver Adapter

HT30

3" to 2 1/2" receiver hitch reducer, black

Weight
3 lb

Std. Pack
1/bulk

* * N E W F O R 2 0 1 7 - 18 * *

Ratchet Straps & Car Tie Downs

TSCF

Ratchet Strap

TSCF has a built-in axle strap

TSF8 TSCF		2" x 8' tie down strap with flat hooks 2" x 10' car tie down strap with flat hooks		Max. Load/ Working Load 10,000/3,333 10,000/3,333		Weight 4.3 lb 4.6 lb		Std. Pack 10/bulk 10/bulk

* * N E W F O R 2 0 1 7 - 18 * *

More Electrical Connectors

F4L1

F4P1

F718

Electrical Connector Extenders

F4L1 F4P1 F4PL F718 F710 P76K	4 way flat with LED test lights, 12" long extender 4 way flat Endurance Easy-Pull, 12" long extender 4 way flat Endurance Easy-Pull with LED lights, 12" long extender 7 way blade type with UL cable, 18" long extender 7 way blade type with UL cable, 10' long extender pre-wired mounting bracket for 7 blade, 7 round & 6 round plugs, black	Weight 0.15 lb 0.25 lb 0.25 lb 0.92 lb 3.47 lb 0.31 lb	Std. Pack 20* 1/clam 1/clam 50 12 20*

*Available carded

* * N E W F O R 2 0 1 7 - 18 * *

Trailer Couplers

ACC6 AC2B

Adjustable Trailer Couplers

Bolt into a channel for multiple raise or drop applications. Quick-locking handle/underjaw design and trigger action mechanism clamps or releases the ball for a fast and easy hook-up.

AC2B
AC3B
ACC6

2" ball - 8,000 lb capacity, black
2 5/16" ball - 14,000 lb capacity, black
6 hole channel for AC2B and AC3B, raw steel finish

Weight
8.8 lb
9.4 lb
7.9 lb

Std. Pack
3/bulk
3/bulk
6/bulk

* * N E W F O R 2 0 1 7 - 18 * *

Trailer Jacks and Winches
